Flow Chart of River Rouge Plant

This flow chart for the Ford Rouge Plant in 1941 shows the sequences by which Ford took raw materials and turned them into finished automobiles. Conveyor belts would have been especially prominent in the motor assembly and car assembly areas at the left center.



Click here to view complete image


Images: From the Collections of The Henry Ford. 1) P.833.75060
